About Sapphire Pulse AMD Radeon RX 9060 XT 16 GB GDDR6
With the Sapphire Pulse Radeon RX 9060 XT-16 GB, enjoy state-of-the-art RDNA 4 performance. This card offers amazing gaming experiences with ray tracing and AI acceleration thanks to its Navi 44 architecture, which has 2,048 stream processors and 32 compute units.
With 32 MB of Infinity Cache and 16 GB of GDDR6 memory clocked at 20 GB/s on a 128-bit interface, it can reach a bandwidth of more than 322 GB/s. With a game clock of roughly 2,700 MHz, factory-overclocked boosts can reach up to 3,290 MHz.
Sapphire’s Dual-X cooling system, which includes composite heatpipes, high-TG copper PCB, AeroCurve fans, and a full metal backplate, controls the thermals and acoustics. With lower loads, fans operate silently at 0 dB idle. It fits most small builds because it only measures 240 × 124 × 46 mm (~2.3 slots).
In addition to supporting PCIe 5.0 connectivity, HDMI 2.1, DisplayPort 2.1a, and AMD’s newest technologies, including FSR4, HYPR-RX, AV1 encoding, and Radeon Anti-Lag 2, it is loaded with features like the Honeywell PTM7950 thermal interface, precision 9-phase power delivery, and RGB logo lighting.
Features of Sapphire Pulse AMD Radeon RX 9060 XT 16 GB GDDR6
| Specification | Details |
|---|---|
| GPU Architecture | AMD RDNA 4 (Navi 44), 2,048 SP, 32 CUs, 32 ray & 64 AI cores |
| Boost Clock | Up to 3,290 MHz |
| Game Clock | Up to ~2,700 MHz |
| Memory | 16 GB GDDR6 @ 20 Gbps, 128‑bit (322 GB/s) |
| Infinity Cache | 32 MB |
| PCIe Interface | PCIe 5.0 x16 |
| Display Outputs | 2× HDMI 2.1, 1× DisplayPort 2.1a |
| Cooling System | Dual-X AeroCurve fans, composite heatpipes, full metal backplate |
| Power Connector | 1×8-pin PCIe |
| Board Power Draw | ~170 W typical |
| Dimensions | 240 × 124 × 46 mm (~2.3 slots) |
| Recommended PSU | 450 W or higher |
| Software Features | FSR 4, HYPR‑RX, Ray Tracing, AV1 encode, Anti-Lag 2 |
| Build Materials | High-TG copper PCB, Honeywell TIM, 9-phase power, RGB logo |
| Warranty | 3 years |
Ideally Best For
- Gamers targeting ultra settings at 1080p and strong entry-level 1440p performance.
- Builders of compact, quiet, and feature-rich PCs.
- Users need future-proof features like FSR 4, PCIe 5.0, HDMI 2.1, and DisplayPort 2.1a.
- Anyone seeking the best balance of VRAM, thermals, and efficiency in a mid-range GPU.
Buy Sapphire Pulse AMD Radeon RX 9060 XT 16 GB GDDR6 Dual‑Fan | PCIe 5.0 Online Today.
