MSI MAG B650M Mortar WiFi mATX Motherboard AM5, DDR5 | PCIe 4.0, Dual M.2 Gen4, Wi‑Fi 6
MSI MAG B650M Mortar WiFi mATX Motherboard AM5, DDR5 | PCIe 4.0, Dual M.2 Gen4, Wi‑Fi 6
Original price was: ₹26,277.00.₹25,657.00Current price is: ₹25,657.00.
MSI MAG B650M Mortar WiFi mATX is a motherboard for AMD Ryzen 7000 series CPUs. Comes with DDR5 support, dual PCIe Gen4 M.2 slots, USB 3.2 Gen2, Wi‑Fi 6E, Bluetooth 5.3, and 2.5G LAN—ideal for performance-packed small form factor builds.
About MSI MAG B650M Mortar WiFi mATX Motherboard AM5
A high-performance micro-ATX motherboard, the MSI MAG B650M Mortar WiFi is made to maximise the capabilities of AMD Ryzen 7000 series processors running on the AM5 platform. It is ideal for gamers, streamers, and creators building in smaller cases because, despite its small size, it offers elite-level connectivity, cooling, and power. With dual-channel architecture and support for up to 128 GB of DDR5 RAM, it offers lightning-fast speeds up to 6400+ MHz (OC), guaranteeing steady performance in taxing workflows like multitasking, gaming, and video editing.
It has two PCIe 4.0 M ports. Four SATA 6Gb/s ports for extra storage options, and two slots for blazing-fast NVMe SSDs. The newest GPUs for demanding gaming or design applications are supported by the reinforced PCIe 4.0 x16 slot with Steel Armor.
The board’s 2.5G LAN, Wi-Fi 6E, and Bluetooth 5.3 networking features provide next-generation wireless speed and low-latency performance for wireless peripherals and online gaming. Extended VRM heatsinks, M.2 Shield Frozr, and a sturdy 6-layer PCB that guarantees steady power delivery all contribute to the thermal performance’s rock stability. Additionally, it has both HDMI and DisplayPort outputs for integrated graphics CPUs and supports USB 3.2 Gen2 Type-C for fast data transfers.
A pre-installed I/O shield, EZ Debug LEDs, and a Flash BIOS Button are examples of build-quality features that make troubleshooting and upgrades simple, even for novice builders. The B650M Mortar WiFi is among the top micro-ATX options in the AM5 lineup because of its combination of power, form factor efficiency, and future-ready support.
Features of the MSI MAG B650M Mortar WiFi mATX Motherboard AM5
| Feature | Specification |
|---|---|
| Chipset / Socket | AMD B650 / AM5 |
| CPU Support | AMD Ryzen 7000 Series |
| Form Factor | micro‑ATX (mATX) |
| Memory Support | 4× DDR5 DIMM, up to 128 GB, 6400+ MHz (OC) |
| Power Design | 12+2+1 Duet Rail VRM, Digital PWM, Core Boost |
| Expansion Slots | 1× PCIe 4.0 x16 (Steel Armor), 1× PCIe 3.0 x1 |
| M.2 Slots | 2× M.2 PCIe 4.0 x4 (w/ M.2 Shield Frozr) |
| SATA Ports | 4× SATA 6 Gb/s |
| Networking | 2.5G LAN, Wi‑Fi 6E, Bluetooth 5.3 |
| Audio | 7.1 Channel HD Audio with Audio Boost |
| Display Outputs | 1× HDMI, 1× DisplayPort |
| USB Ports | USB 3.2 Gen2 Type‑C, Gen1, and USB 2.0 |
| Cooling | Extended heatsinks, 6-layer PCB, thermal pads |
| Extras | Flash BIOS Button, EZ Debug LEDs, RGB headers |
Ideally Best For
- Small-Form Gaming PCs need high-end power in tight spaces
- Creators & Streamers using Ryzen 7000 CPUs and fast storage
- Modern PC Builders looking for Wi‑Fi 6E, USB-C, and PCIe 4.0
- DIY Enthusiasts who prefer mATX but need full-size features
- Upgrade Planners building on AM5 for future Ryzen compatibility
