About MSI GeForce RTX 5060 Ti GAMING TRIO OC 16GB GDDR7 Graphics Card
16GB GDDR7 & Blackwell Power While standard mid-range cards often feature 8GB of VRAM, this GAMING TRIO edition is equipped with 16GB of GDDR7 memory. This massive buffer, combined with the NVIDIA Blackwell architecture, ensures the card can handle high-resolution textures and future AAA games without running out of video memory. It fully supports DLSS 4 with AI Multi-Frame Generation, delivering significantly higher frame rates than previous generations.
TRI FROZR 4 Thermal Design The card stays cool under pressure thanks to the updated TRI FROZR 4 cooling system. It utilizes three TORX Fan 5.0 units, where fan blades are linked by ring arcs to focus airflow into the heatsink. The new STORMFORCE fan design optimizes air pressure while reducing noise. A nickel-plated copper baseplate rapidly captures heat from the GPU and memory, transferring it to square-shaped Core Pipes for efficient dissipation.
Signature Gaming Style The GAMING TRIO series is famous for its bold aesthetic. The card features aggressive angular styling highlighted by customizable Mystic Light RGB on the shroud and side logo, which can be synced with other MSI components. A sturdy metal backplate reinforces the card to prevent sagging and features flow-through vents to allow hot air to escape, ensuring your system runs as good as it looks.
MSI GeForce RTX 5060 Ti GAMING TRIO OC 16GB GDDR7 Graphics Card Specifications:
| Graphics Engine | NVIDIA GeForce RTX 5060 Ti |
| Bus Standard | PCI Express 5.0 x16 (uses x8) |
| Video Memory | 16GB GDDR7 |
| Memory Interface | 128-bit |
| Core Clock | 2662 MHz (Extreme Performance) / 2647 MHz (Boost) |
| CUDA Cores | 4608 Units |
| Memory Speed | 28 Gbps |
| Cooling System | TRI FROZR 4 (Triple TORX Fan 5.0) |
| Output | 3x DisplayPort 2.1b, 1x HDMI 2.1b |
| Power Connectors | 1 x 16-pin (12V-2×6) |
| Recommended PSU | 600W |
| TDP | 180W |
| Card Dimensions | 300 x 125 x 44 mm (2.2-Slot) |
| Feature Support | DLSS 4, Ray Tracing, Mystic Light RGB |
Key Features
-
16GB GDDR7 Memory: Future-proof capacity for high-texture 1440p gaming.
-
TRI FROZR 4 Cooling: Advanced thermal design with TORX 5.0 fans.
-
Factory Overclock: Boost clock increased to 2647 MHz+ for extra speed.
-
Mystic Light RGB: Fully customizable lighting synchronisation.
-
Dual BIOS: Physical switch for Gaming or Silent operation modes.
