About Gigabyte B650M H Gaming Motherboard
| Category | Specification Details |
|---|---|
| CPU | AMD Socket AM5, supports Ryzen 7000 / 8000 / 9000 Series Processors |
| Chipset | AMD B650 |
| Memory | 2× DDR5 DIMM sockets, up to 128 GB, Dual Channel, EXPO/XMP support |
| Graphics | Integrated DisplayPort 1.4 & HDMI 2.1 (depends on CPU iGPU) |
| Audio | Realtek HD Audio Codec, multi-channel support |
| LAN | Realtek GbE LAN (1 Gbps) |
| PCIe Slots | 1× PCIe 4.0 x16, 1× PCIe 3.0 x1 |
| Storage | 1× M.2 (PCIe 4.0 x4), 4× SATA 6Gb/s |
| USB Ports | USB 3.2 Gen1, USB 2.0 (exact count varies) |
| Cooling | Smart Fan 6 support (multiple fan headers) |
| BIOS Features | Q-Flash Plus (BIOS update without CPU/DRAM) |
| Form Factor | Micro-ATX (24 × 24 cm approx.) |
| Memory Speed (OC) | Up to DDR5-7200 (varies rev) |
| Smart Features | EZ-Latch PCIe slot, Smart Fan controls |
Key feature about the Gigabyte B650M H Gaming Motherboard
-
The Gigabyte B650M H Gaming Motherboard supports AMD Socket AM5 processors from Ryzen 7000, 8000, and 9000 series for broad CPU compatibility.
-
Gigabyte B650M H Gaming Motherboard chipset platform optimized for gaming and general performance.
-
Durable 5+2+2 phases digital VRM power design for stable CPU power delivery.
-
Dual-channel DDR5 memory with support for EXPO and XMP profiles.
-
Memory overclocking support beyond standard speeds for faster multitasking.
-
PCIe 4.0 x16 slot for graphics card compatibility and bandwidth.
-
PCIe 4.0 x4 M.2 connector for high-speed NVMe SSD storage.
-
The Gigabyte B650 Series Durable Motherboard Four SATA 6 Gb/s ports for additional SATA storage devices.
-
Integrated HDMI 2.1 support for high-resolution display output.
-
DisplayPort 1.4 output supporting high refresh monitors.
-
Realtek Gigabit LAN for reliable wired network performance.
-
Thw Gigabyte B650 Series AMD Motherboard support for RAID 0/1/10 configurations on SATA and NVMe drives.
-
Q-Flash Plus button enables BIOS updates without CPU or memory installed.
-
Smart Fan 6 cooling in the Gigabyte DDR5 Series Gaming Motherboard support with multiple fan headers and temperature sensors.
-
EZ-Latch PCIe slot makes graphics card installation and removal easier.
-
Supports high-definition multi-channel audio with noise isolation design.
-
AMI UEFI BIOS provides intuitive firmware control and settings customization.
-
Micro-ATX form factor fits compact builds without sacrificing expandability.
-
Multiple USB ports (Gen1 and Gen2) for peripherals and external devices.
-
Supports both legacy and modern operating systems, including Windows 10 and 11.
