About ASUS Prime GeForce RTX 5060 OC Edition 8GB GDDR7 Graphics Card
Primed for Performance The ASUS Prime series is designed to offer a premium experience without unnecessary bulk. This RTX 5060 model features a slim 2.5-slot design (50mm thick) and a length of just 268mm, making it officially “SFF-Ready Enthusiast” compatible. It fits easily into smaller chassis while still providing the superior airflow of a triple-fan setup, ensuring your system runs cool and quiet under load.
Blackwell Architecture & GDDR7 Built on the next-gen NVIDIA Blackwell architecture, this card features 3840 CUDA cores and 8GB of ultra-fast GDDR7 memory. This combination ensures smooth high-FPS gameplay in modern titles. While fully compatible with PCIe 4.0 motherboards, it natively supports PCIe 5.0 for maximum future-proofing. It is also ready for DLSS 4, utilizing AI Frame Generation to boost performance significantly.
Advanced Cooling & Durability The card utilizes three Axial-tech fans with smaller hubs and longer blades to increase air pressure through the heatsink. The fans employ dual-ball bearings, which last up to twice as long as sleeve bearings. For reliability, the card is manufactured using Auto-Extreme Technology, an automated process that reduces thermal strain on components. A vented metal backplate reinforces the PCB and helps dissipate heat.
ASUS Prime GeForce RTX 5060 OC Edition 8GB GDDR7 Graphics Card Specifications:
| Graphics Engine | NVIDIA GeForce RTX 5060 |
| Bus Standard | PCI Express 5.0 x8 (Backwards Compatible with 4.0) |
| Video Memory | 8GB GDDR7 |
| Memory Interface | 128-bit |
| Core Clock | 2595 MHz (OC Mode) / 2565 MHz (Default) |
| CUDA Cores | 3840 |
| Memory Speed | 28 Gbps |
| Cooling System | Prime Triple Fan (Axial-tech) |
| Output | 3x DisplayPort 2.1b, 1x HDMI 2.1b |
| Power Connectors | 1 x 8-pin |
| Recommended PSU | 550W |
| TDP | 145W |
| Card Dimensions | 268.3 x 120 x 50 mm (2.5-Slot) |
| Feature Support | DLSS 4, Ray Tracing, SFF-Ready |
Key Features
-
8GB GDDR7 VRAM: High-speed memory for fast texture loading.
-
Triple-Fan Cooling: Axial-tech fans for superior thermal management.
-
SFF-Ready: Optimised 2.5-slot dimensions for compact builds.
-
Dual BIOS: Switch between Performance and Quiet profiles physically.
-
0dB Technology: Fans stop completely during light loads for silence.
