About NZXT Chassis H7 Flow RGB White Mid Tower
| Category | Specification Details |
|---|---|
| Model Name | NZXT H7 Flow RGB |
| Chassis Type | Mid Tower |
| Color Finish | Matte White |
| Frame Material | SGCC Steel |
| Side Panel Material | Tinted Tempered Glass |
| Motherboard Compatibility | E-ATX (≤ 277 mm), ATX, Micro-ATX, Mini-ITX |
| Expansion Slots | 7 Standard Slots |
| Included Fans | 1 × F360 RGB Core (Triple 120 mm) |
| Total Fan Capacity | Up to 10 Fans |
| Front Fan Support | 3 × 120 mm or 3 × 140 mm |
| Top Fan Support | 3 × 120 mm or 2 × 140 mm |
| Bottom Fan Support | 3 × 120 mm |
| Rear Fan Support | 1 × 120 mm or 1 × 140 mm |
| Front Radiator Support | Up to 420 mm |
| Top Radiator Support | Up to 360 mm |
| Rear Radiator Support | Up to 140 mm |
| Maximum GPU Length | Up to 410 mm |
| Maximum CPU Cooler Height | Up to 185 mm |
| PSU Compatibility | Standard ATX PSU |
| Storage Drive Bays | 2 × 3.5” HDD, 4 × 2.5” SSD |
| Cable Management Space | Up to 34.5 mm |
| Dust Filters | Front, Top, Bottom |
| Front I/O Ports | 2 × USB-A, 1 × USB-C, 1 × Audio Combo Jack |
| RGB Support | Addressable RGB (5V ARGB) |
| Case Orientation | Vertical Tower Layout |
At the core of the H7 Flow RGB is its airflow-optimized mesh front panel, engineered to allow unrestricted air intake.
This design significantly improves cooling efficiency, enabling components such as CPUs and GPUs to operate at optimal temperatures even during demanding workloads.
The open structure ensures consistent airflow throughout the chassis, reducing heat buildup and enhancing overall system stability.
The case features a spacious interior layout that supports a wide range of modern hardware.
With compatibility for E-ATX, ATX, Micro-ATX, and Mini-ITX motherboards, the H7 Flow RGB provides flexibility for both compact and full-sized builds.
It accommodates high-performance graphics cards up to 410 mm in length and tall CPU air coolers up to 185 mm, making it suitable for the latest generation of components.
Cooling flexibility is a standout feature of this mid tower chassis.
The H7 Flow RGB supports up to ten fans and large radiators, including up to 420 mm in the front and 360 mm at the top.
This allows builders to configure advanced air or liquid cooling setups tailored to their performance needs.
The included F360 RGB Core fan delivers powerful airflow while adding dynamic lighting effects that enhance the system’s appearance.
A tinted tempered glass side panel provides a clear view of internal components, allowing RGB lighting, custom cooling solutions, and carefully managed cables to be showcased.
The matte white exterior adds a clean and modern aesthetic that complements both minimalist and RGB-heavy builds, making the system visually striking without appearing cluttered.
NZXT has prioritized ease of assembly and cable management in the H7 Flow RGB.
Integrated cable routing channels, ample clearance behind the motherboard tray, and reusable Velcro straps simplify cable organization.
This not only improves aesthetics but also promotes better airflow and easier maintenance.
The front I/O panel offers modern connectivity options, including USB Type-A ports, a USB Type-C port, and a combined audio jack.
These ports provide convenient access for peripherals, external storage, and headsets, enhancing everyday usability.
Dust protection is handled through strategically placed filters on the front, top, and bottom of the chassis.
These filters help maintain a clean internal environment, reducing dust accumulation and extending the lifespan of internal components.
Overall, the NZXT Chassis H7 Flow RGB White Mid Tower is a well-rounded solution for PC builders seeking high airflow performance, premium build quality, and eye-catching RGB lighting.
Its thoughtful design, extensive cooling support, and elegant white finish make it an excellent foundation for powerful and visually impressive PC builds.
