About INNO3D GeForce RTX 5070 X3 OC Graphics Card
Specification | Details |
---|---|
GPU Engine Specs | |
CUDA Cores | 6 144 |
Base Clock | 2 325 MHz |
Boost Clock | 2 542 MHz |
Memory Specs | |
Memory Type | GDDR7 |
Memory Capacity | 12 GB |
Memory Interface Width | 192‑bit |
Memory Clock | 28 Gbps |
Memory Bandwidth | ~672 GB/s |
Feature Support | |
Real‑Time Ray Tracing | Yes – 4th Gen RT Cores, ~94 TFLOPS |
Tensor Cores | 5th Gen – ~988 AI TOPS |
DLSS Support | DLSS 4 with Multi‑Frame Generation |
NVIDIA Reflex | Reflex 2 with Frame Warp |
NVIDIA Studio & Broadcast | Yes |
PCI Express | Gen‑5 |
APIs | DirectX 12 Ultimate, Vulkan 1.4, OpenGL 4.6 |
NVENC / NVDEC | 1× 9th‑Gen Encoder, 1× 6th‑Gen Decoder |
AV1 Encode/Decode | Both supported |
Multi‑Monitor Support | Up to 4 displays |
Max Resolution | 4K @ 480 Hz or 8K @ 165 Hz (with DSC) |
Outputs | 3× DisplayPort 2.1b, 1× HDMI 2.1b |
HDCP Version | 2.3 |
Dimensions & Design | |
Length | 300 mm |
Height | 116 mm |
Width | 41 mm (2‑slot SFF) |
Cooling & Build | |
Fans | Triple 88 mm scythe‑blade fans |
Heatpipes | 6× nickel‑plated composite |
Copper Baseplate | GPU coverage + heatpipe integration |
Aluminum Baseplate | Dedicated memory heat dissipation |
Fin Design | Optimized thickness & spacing for airflow |
Backplate | Multi‑functional – airflow and PCB protection |
Noise Control | Low‑noise fan blade design |
Power Efficiency | |
Typical Card Power (TGP) | ~250 W |
System Power Requirement | Min. 650 W PSU |
Power Connectors | 2× PCIe 8‑pin cables (or ≥300 W PCIe Gen‑5 |
