About Gigabyte C200G TG Panel Cabinet
| Specification | Details |
|---|---|
| Case Model | Gigabyte C200G TG Panel (also called C200 Glass / GB-C200G) |
| Materials | Steel frame, tempered glass front & side panels, plastic components, PSU shroud |
| Motherboard Compatibility | Supports ATX, micro-ATX, Mini-ITX motherboards |
| Dimensions | Height ~ 480 mm; Width ~ 210 mm; Depth ~ 435 mm (± ~1%) |
| Expansion Slots | 7 slots for PCI(e) cards |
| Drive Bays / Storage Mounts | 2 bays (3.5″ or 2.5″) for HDD/SSDs; plus 2 additional 2.5″ bays for SSDs |
| I/O Panel | 2 × USB 3.0 ports; RGB LED switch; Reset button; Audio In/Out jacks |
| Fan Support | Pre-installed 1 × 120 mm rear fan; Top: space for 2×120 mm or 2×140 mm; Front: 3×120 mm or 2×140 mm |
| Radiator / Liquid Cooling Support | Rear: 120 mm; Top: 240 mm or (2 × 120 mm); Front: up to 280 mm radiator supported |
| PSU / GPU / CPU Clearances | PSU max length ~ 170 mm; GPU max length ~ 330 mm; CPU cooler max height ~ 165 mm |
| Dust Filtering | Detachable filters at top and bottom to reduce dust intake |
| PSU Shroud | Fully enclosed PSU shroud to hide PSU and cables, improve aesthetics / airflow |
| RGB / Lighting | Integrated RGB lighting in front panel; RGB LED switch to change effects; tempered glass panels for visibility |
| Weight | Net weight about 7.24 kg |
| Miscellaneous Features | PSU shroud; full-size tempered glass side panel; easy cable management; detachable filters; front RGB control |
