About Deepcool CH260 Black Mid Tower Cabinet
| Category | Specification / Capability |
|---|---|
| Product Dimensions (L × W × H) | 438 × 225 × 312.5 mm |
| Net Weight | 5.3 kg |
| Materials / Construction | ABS plastic + SPCC (steel) + Tempered Glass side panel |
| Motherboard Support | Mini-ITX, Micro-ATX, and Micro-ATX rear connector types |
| Front I/O / Ports | 2 × USB 3.0 Type-A 1 × USB 3.2 Gen2 Type-C 1 × combo audio/mic jack |
| Drive Bays | 3.5″: 1 2.5″: 1 |
| Expansion Slots | 4 slots |
| Fan Support | Front: 2 × 120 mm Top: 3 × 120 mm or 2 × 140 mm Rear: 1 × 120 mm |
| Radiator / Liquid Cooling Support | Top: 120 / 240 / 360 mm radiators Rear: 120 mm radiator Front: none (not supported) |
| CPU Cooler Height Limit | 174 mm |
| GPU / Graphics Card Limit | Up to 388 mm with front fans installed; up to 413 mm if front fans are omitted |
| Power Supply Support | ATX (PS2) up to 150 mm length |
| Other Design / Structural Features | Full mesh front and top panels for improved airflow Tempered glass side panel to showcase components Rear connector/backplane clearance (for rear I/O motherboards) and expanded backplane space ~ 29.6 mm Modular PSU mounting bracket to ease cable routing |
With an external footprint measuring 438 × 225 × 312.5 mm and a weight of about 5.3 kg, it offers a balance between compactness and expandability, making it ideal for users who want a smaller system without overly sacrificing hardware support.
One of the Deepcool CH260 Black Mid Tower Cabinet standout traits is its mesh-heavy design — the front and top panels are fully meshed, wrapping the case in a breathable shell that allows ambient air to flow in, while heat is let out more effectively.
This opens up strong thermal headroom even when pushing high-performance components.
Though compact, the case supports a wide range of hardware.
GPUs of up to 388 mm in length are supported while retaining front fans; removing the front fans expands the limit to 413 mm, giving users wiggle room for large dual- or triple-fan graphics cards.
The CPU cooler height ceiling sits at 174 mm, which accommodates many high-performance air coolers.
For liquid cooling enthusiasts, the Deepcool CH260 Black Mid Tower Cabinet can host top-mounted 360 mm radiators and rear-mounted 120 mm radiators, giving flexibility in cooling layouts.
Motherboard compatibility includes Mini-ITX and Micro-ATX boards, including rear-connector (backplate / I/O) mATX boards, aided by generous backplane clearance (~ 29.6 mm) to accommodate connectors and wiring.
For power supplies, Deepcool CH260 Black Mid Tower Cabinet supports standard ATX PS2 units up to 150 mm in length via a removable mounting bracket — a clever design choice that simplifies cable routing and installation, especially in tighter builds.
Internally, the layout facilitates improved cable management and airflow.
The tempered glass side panel allows for a clean visual presentation of components, letting builders show off RGB, cables, and hardware.
Removable dust filters and modular features help with maintenance.
The design emphasizes that even in a mid-compact form, you can still build high-performance, thermally efficient systems with aesthetic flair.
The Deepcool CH260 Black Mid Tower Cabinet is a compelling option for those who want a compact, airflow-optimized case that doesn’t compromise on hardware compatibility or style.
Its support for long GPUs, decent cooling options, and clean presentation make it attractive for gaming, workstation, or versatile builds that need to stay within a smaller footprint.
