About DarkFlash DY460 ATX Black Desktop Cabinet
| Category | Specification |
|---|---|
| Model Name | DarkFlash DY460 ATX (Black) |
| Chassis Type / Design | Mid-tower / ATX dual-chamber vertical layout |
| Build Materials | 0.8 mm SPCC steel frame + three tempered-glass panels (panoramic) |
| Motherboard Compatibility | ATX, Micro-ATX, Mini-ITX |
| Expansion (PCI-Express) | 7 slots |
| Storage / Drive Bays | 2 × 3.5″ HDD, 1 × 2.5″ SSD |
| GPU Support | 400 mm length (horizontal) or up to 385 mm (vertical, with accessory) |
| CPU Cooler Support | Up to 185 mm height |
| Power Supply Support | ATX PSU, up to ~200 mm length |
| Fan / Air Cooling Support | – Top: 3 × 120 mm – Side: 3 × 120 mm – Bottom: 3 × 120 mm – Rear: 1 × 120 mm; total up to 10 fans |
| Liquid Cooling Support | Top: 360 / 240 / 120 mm radiator; Rear: 120 mm radiator |
| Front / Top I/O Panel | USB 3.2 Gen 2 Type-C × 1, USB 3.0 × 1, HD Audio, Power / Reset buttons |
| Airflow Design | Louvered side vents in lower chamber + raised base to draw in cool air and improve airflow |
| Dust Filtration | Magnetic dust filters for easy maintenance |
| Vertical GPU Support | Yes, supports vertical GPU mounting (with optional bracket) |
| Accessory Pack | Comes with a premium accessory box for organization |
At its heart, the DY460 uses a dual-chamber, vertical layout.
Unlike traditional cases, it divides the interior into two functional zones: one for the PSU and storage and another for the motherboard, GPU, and cooling system.
This thoughtful design not only helps with cable management but also improves airflow, drawing cool air in through louvered vents around the lower chamber.
The elevated base further promotes efficient intake, allowing warmer air to exit cleanly.
One of the most striking visual features of the DY460 is its three-sided tempered glass panels, which give you roughly a 330° panoramic view of your build.
This setup allows your graphics card, custom cooling loops, RGB lighting, and clean cable work to be displayed beautifully.
It’s an excellent choice for builders who want their system not just to perform well but also to look great from almost every angle.
When it comes to cooling, the case is exceptionally capable.
It supports up to ten 120 mm fans — with mounting options on the top, side, bottom, and rear — giving you extensive flexibility to fine-tune airflow.
For liquid cooling users, the top panel accommodates a 360 mm radiator, and the rear supports a 120 mm radiator, making the case very friendly for AIO or custom loop setups.
This ensures that even powerful CPUs and GPUs can be cooled effectively.
The DY460 doesn’t lag behind in component compatibility either.
It supports full-size ATX motherboards as well as smaller Micro-ATX and Mini-ITX boards, ensuring flexibility for different build types.
It offers ample room for GPUs up to 400 mm in horizontal layout, and even vertical GPU mounting is possible with an optional bracket — a feature that boosts aesthetics and potentially enhances airflow.
For cooling, clearances go up to 185 mm for CPU coolers, which accommodates many high-performance air coolers.
Storage options are practical, with support for two 3.5″ HDDs and one 2.5″ SSD, striking a balance between capacity and performance.
Power supply support is robust too, allowing ATX PSUs of up to 200 mm in length, giving room for high-wattage units.
On the I/O front, the DY460 features a high-speed USB 3.2 Gen 2 Type-C port, along with a USB-A port and HD audio connectors.
Power and reset buttons are intuitively placed, making daily use simple and efficient.
Dust control is another area where this case shines.
Magnetic dust filters on the vents allow for easy removal and cleaning, helping to maintain a clean build without much hassle.
This ensures your system stays fresh and performs optimally.
Overall, the DarkFlash DY460 ATX Black Cabinet is an excellent choice for those who want a compact but capable build.
It offers strong thermal design, modern connectivity, and a stunning visual display — all packed into a space-efficient form factor.
Whether you’re building a high-performance gaming rig, a streaming workstation, or a powerful all-purpose desktop, the DY460 delivers on both style and substance.
